8 cbm sewage tank is installed on 6 wheel dongfeng cargo chassis, have 8 cbm sewage capacity, equipped with China top vacuum pump, all necessary pipeline and valve, etc. 8 cbm sewage tank is made of 5mm high quality carbon steel, 8 cbm sewage tank is designed according to fact environment protection need in China city. Can dispose all kinds sewage water, sludge, waste water, etc.
8 cbm sewage tank mounted on dongfeng mature cargo chassis , equipped with Dongfeng Cummins engine, have very high reputation in Africa. Really use worry-free, safe and reliable.
|
 |
 |
 |
Dongfeng 8 Cbm Sewage Tank
Product Features
-
Self-priming, self-discharging, rear door opening and closing controlled by Hydraulic
-
Mounted with China top WEILONG brand vacuum pump with large suction power and long suction distance
-
Option high pressure cleaning, watering, etc function.
Main parameter
|
Product Name |
DONGFENG 8 cbm sewage tank |
|
Driving Type |
4×2 |
|
Weight /Volume |
|
|
Tank Volume(cbm) |
8 |
|
Rated payload weight(kg) |
8000 |
|
Dimensions |
|
|
Wheelbase(mm) |
3970 |
|
Overall Dimension(mm) |
7895×2300×3100 |
|
Engine |
|
|
Engine brand & model |
DONGFENG Cummins,B170 33 |
|
Engine type |
4 stroke, water-cooled, straight line 6 cylinders, diesel |
|
Displacement(L)/Power(kw) |
5.9/125 |
|
Chassis |
|
|
Axle Quantity |
2 |
|
Transmission Type |
FAST 8 forwards,1 reverse gear, manual |
|
Steering Type |
LHD or RHD with power steering |
|
Brake system |
Air brake |
|
Tire Spec. & size |
9.00R20, 6 with a spare |
|
Cab |
|
|
Standard configuration |
Flat proof, single sleeper, electric window, central lock, radio |
|
Air conditioning |
Have |
|
Performance parameter of dongfeng 8 cbm sewage tank |
|
|
Tank shape |
Cylinder body |
|
Tank material |
Q235 carbon steel 5mm shell, 6 mm cover head( option: stainless steel) |
|
Standard configuration |
1.with one high quality Weilong brand special vacuum pumps, vertical suction lift is about 7-9m. |
|
2.Accessory: inspect window, one gravity mouth, cleaning apparatus, 5 meter long suction pipe, oil-water separators, overflow valve, rear door controlled by hydraulic, etc, |
|
Product detail
